ENGLISH
• CEDIMA
®
• Technical Documentation • All rights reserved as per DIN 34 • Subject to modifications due to progressive development •
Contents of the operating manual
Joint Cutter CF-12.4 E-TR
Uniform Statement of Conformity
Preface
CHAPTER 1 Technical specifications and accessories
1.0 Technical specifications of the joint cutter CF-12.4 E-TR 1-1
1.1 Sound ranging 1-1
1.2 Items supplied with the machine 1-1
CHAPTER 2 Description of the joint cutter
2.0 Description of the joint cutter CF-12.4 E-TR 2-1
CHAPTER 3 General safety instructions
3.0 General/basic safety instructions for joint cutters 3-1
3.1 Warnings and symbols 3-1
3.2.1 Principle of proper use 3-1
3.2.2 Organisational measures 3-1
3.2.3 Selecting qualifi
ed staff; general duties 3-2
3.2.4 Safety information on certain operation phases 3-2
I - Normal operation 3-2
II - Special work related to the use and maintenance
of the machine as well as fault clearing and disposal 3-4
3.2.5 Information on special risks related to electricity 3-5
3.2.6 Gas, dust, vapour, smoke 3-5
3.2.7 Noise 3-5
3.2.8 Lighting 3-6
3.2.9 Oils, greases and other chemical substances 3-6
3.2.10 T
ransporting the machine 3-6
CHAPTER 4 Installation and operation
4.0 Installation and operation 4-1
4.0.1 To be checked on delivery 4-1
4.1 Preparing the joint cutter 4-1
4.1.1 Adjusting the push handle 4-1
4.1.2 Checking the tension of the V
-belts 4-1
4.2 Mounting the diamond saw blade 4-1
4.2.1 General notes on mounting 4-1
4.2.2 Opening the blade guard and raising the cutting shaft 4-2
4.2.3 Mounting the diamond saw blade 4-2
4.3 Activating and adjusting the fi
xing brake 4-4
4.4 Adjusting and using the front pointer 4-5
4.5 Dry cutting 4-5
4.6 Starting and stopping the CF-12.4 E-TR motor 4-6
4.6.1 Starting the CF-12.4 E-TR motor 4-6
4.6.2 Stopping the CF-12.4 E-TR motor/emergency stop 4-7
4.7 Adjusting the cutting depth 4-7
4.8 Cutting operation 4-8
4.9 Finishing the cutting operation 4-8
4.10 Replacing the diamond saw blade 4-8
