Maintenance and care
CF•13.3 B / CF•13.3 B-L
ENGLISH
Tension the V-ribbed belt according to section 6.7.1!
22. Plug the saw blade holder ange onto the left side of
the cutting shaft, parallel key
Figure 6.20
24
10
21. V-ribbed belt guard cover mounted with screws
Figure 6.19
17
20. Tension the V-ribbed belt
Figure 6.18
23. Push the saw blade holder ange with the cutting shaft
nut onto the left cutting shaft side
Figure 6.21
Align the saw blade holder ange according to the
parallel key on the cutting shaft
(gures 6.20 and 6.21)!
