4
Direct TENS
™
6. Switch the therapy unit on
7. Select a program (only possible when intensity = 0)
The program depends on the indication to treat, see also chapter 2.2 / page 13
OR
8. Set intensity for selected channel
9. After approx. 10 seconds the keys are automatically locked
to prevent the treatment parameters
from being changed inadvertently. To unlock the keys, press either
key (channel 1 or 2).
10. To terminate the treatment simply turn o the device with the ON/OFF key. When the therapy timer
is activated, the stimulator switches automatically o at the end of the programmed interval.
Note: The Belt Clip can be attached or removed as required. You can find the procedure to attach/remove the
belt clip on page 16, chapter 3.1.
QUICK START GUIDE
