Drill/Driver - Specifications and Know Your Product 5.1
Drill/Driver - Know Your Product
5.1
Know Your product
1. Variable power trigger/Stop
2. MPB(Direction selector/lock)
3. Soft grip
4. Motor cooling vents
5. Keyless chuck
6. 2 Speed gearbox selector
7. Torque/Hammer selector
8. Replaceable brush cover
9. Battery cooling vents
10. Handle release latch
11. Driver bit
Voltage: 18V
No load speed: 0-350, 0-1,250 RPM
Torque settings: 20 Positions
Max drilling capacity:
Steel 1/2” (13 mm)
Wood 1 1/10” (28 mm)
Concrete 1/2” (13 mm)
Hammer impact frequency:
0-5,600, 0-20,000 min
-1
Single Sleeve
Drill chuck capacity:
Weight: (WS1-HD01) 4.3lbs (2.4 kg)
Specifications
½” (13 mm) keyless
Weight: (WS1-LD01) 4.7lbs (2.1 kg)
Double Sleeve
Drill chuck capacity:
(10 mm) keyless
NOTE. Hammer Mode is not available on drill model WS1-LD01
