Scroll Saw - Assembly
12.3
5. Close the lid. Snap shut both
the case latches.
6. The table clamp can be fitted to
press the work piece against the
work surface. First install the post
into the vertical position at the
highest level. Rotate the
adjustment knob until the open
jaws can be passed over the post.
Align the bar ends to fit onto the
holes on the post and re-tighten to
secure in place. The tighter the
adjustment to the clamp knob the
more pressure is applied to hold
down your work.
7. Only after full installations and
adjustments have been made
should the POWERhandle be
fitted into the charger dock to
enable the product.
8. The scroll saw is started and
stopped by the main case
operation ON/OFF button above
the charger dock.
Scroll Saw - Operating Instructions
12.4
Making Poc et C t
k
u
s
1. Use the drill press or drill to bore a hole on the
inside of the area you want to
remove, close to
the cutti
g line. Ensure that the drill d amet
r is
n i
e
grea
er than th blade by 1
r 2mmt e
o
2. Place he hol
over the scroll saw blade and
t
e
align
he cutting face of t
e blade with the
t
h
direction of cut and your marked line. For this
operation you will have to remove the table
clamp or
lid
your work underneath it. Now s
e
continue to stage 2 of ‘Making Cuts’.
Making T
ig t or Corner Cuts
h
NOTE: Don’t try and cut a cur
e which is
too
v
tight
by forcing the blade
This will put undue
.
pressure on the blade causing it to snap.
If you intend to make a pocket cu
with internal
t
rounded corners it is best to use the drill press
first with the cor ect diameter drill.
r
For exter
al corners contin e your cut past the n u
your mark and then realign t e work piece with
h
the blade facing in the correct d rection.i
Or
When you ge to the tight external corner move t
the
work piece gently ba
k and forward at the
c
same time rotating the work in the desired
direction to e large the cut width so the blade
n
can tu
n enough t align w
th your marked r o
i
direction.
Making Cuts
CAUTION. Always ensure that the scroll saw is
switched off and the POWERhandle is removed
before making any adjustments.
1. First insure that you have install the correct
blade into the jigsaw for the material and design
you are about to cut. Wood blade for all types of
wood and a metal blade for metals and plastics.
2. Before starting the scroll saw or installing a
POWERhandle into the charger dock adjust the
table clamp so that it firmly presses your work
piece against the work surface but still allows
easy movement.
3. Align the first cut with the cutting face of the
blade with a small gap; holding your work piece
with your right hand, start the scroll saw with
your left.
4. Grip your workpiece on both sides of the table
clamp and gently push it into the cutting face of
the scroll saw. Firmly but smoothly guide the
work over the blade following your marked
design. Depending on the material of your work
piece you might have to blow the dust away to
keep good visibility of your marked cut line.
5. When you have completed your cut hold the
work steady with you right hand and stop the
scroll saw with your left.
Making Bevel Cuts
The jigsaw can be adjusted to lean 10° in either
direction to enable a bevel cut.
65
