Drill Press - Assembly
11.3
5
4
6
Switching Drill Press On and Off
NOTE: Ensure that all body parts are clear of
the cutting tool before installing a
POWERhandle.
1. To start the machine, press the green
operation button on the main case.
2. The machine will now run continuously.
3. To stop the machine, press the Red operation
Button on the main case.
Making a Cut
Fit a cutting tool such as a drill bit into the chuck
as described in point 4.
Adjust the height of the drill press by lifting the
latches which lock the post in place and slide the
post into the correct location; ensure the latch is
flush with the work surface again before
proceeding.
Select a suitable gear for your cutting tool and
material. Low gear for large drill bits and cutting
metal and high gear for small drills and softer
materials.
NOTE: Make a test cut in scrap wood before
cutting your work.
NOTE: Put scrap material under the work piece
you are cutting to stop damage to the work
surface.
Warning
. Never start th
drill press with thee
cutting tool on the ork piece.w
NOTE: Make sure the jigsaw and circular saw
are NOT ins
alled onto the case lid and the t
internal plug is NOT connec
ed to a pr
duct.
he t
o
T
drill p
ess will not work if the jigsaw or cir ular
r
c
saw are installed or the case lid is shut and
latched.
The drill press is s arted and stopped by the
t
main case operat on ON/OFF button above the i
charger dock.
Start the drill, pul
the post lever downwardsl
slowly
, align your marking with the cutting tool tip
nd con inue to pull the drill s owly through your
a
t l
work piece. Let the drill do the wo
k; don’t force r
it through or your work will snag.
Return the leve to its upper po
ition, then stop
r
s
the drill At all time
you must ensure your work
. s
piece is held firmly a ainst the work surface.
g
CAUTION.
Always ensure that the table saw is
switched off and the POWERhandle is removed
before making any
djustments.
a
Drill Press - Operating Instructions
11.4
4. Add your required cutting tool to the drill’s chuck and tighten
firmly. If further height adjustment is required please refer to
stage 3.
5. The post lever can be fitted to either side to allow for left or
right handed use. Slide the front pin to the moving part of the
post and the other pin into the elongated hole on the stationary
part of the post. The drill should move down when the handle is
pulled downwards.
Use the post handle to pull down the drill press and make sure
the drill bit will not touch the work surface when it is fully pulled
down; at this point you may need to adjust the height again.
6. If using a drill with a tip 10mm or less then it is possible to use
the table clamp to hold your work. Unwind
the clamp knob until the open jaws can fit
over the post and into the holes. Align the
clamp pins into a pair of holes on the post
and tighten the knob again. Place your
work piece on the work surface in the
correct position and further tighten the
clamp until your work is firmly held in
position.
