Post and Protractor - Know Your Product
14.1
1. Angle markings
2. Angle release knob
3. Angle indicator
4. Spirit level (1of3)
5. Post lock holes
6. Finger recess
7. Post hook
8. Post head release button
9. Post head pivot
10. Post head (sliding part)
11. Handle pin location hole
12. Handle pin location slot
13. Electrical contacts
14. Post head (swing part)
15. Post hook (active)
16. Product release latch
17. Post lever
18. Handle Release latch
Post and Protractor - Know Your Product 14.1
17 1 2 3 4 5 6 7
16 15 14 13 12 11 10
9
8
