POWERED SUBWOOFER
SPECIFICATIONS
12) LINE OUTPUT
LINE IN @ 1KHz 1V INPUT
( 0 dB O/P Ref )
Freq VOL Set to Max. 1.3 +/-10% V
13) SPEAKER OUTPUT
HI PASS FILTER -3dB 130 +/-10% Hz
( SPEAKER IN @1KHz )
@ 4 Ohm Load
14) SPEAKER OUTPUT
HI PASS FILTER ROLL-OFF 7 +/-1 dB
SPEAKER IN @ 1KHz
( 0dB 1W 0/P Ref )
@ 4 Ohm Load
15) INPUT IMPEDANCE
RCA 20K 15K OHM
SPEAKER 200 +/-10 OHM
16) AUTO TURN ON LEVEL 2.5 +/-1 mV
17) AUTO OFF DELAY TIME 50 40 Min
18) PHASE ADJUSTABLE 0- 180 0-170 Degree
@ 55-65Hz 10V O/P 0 Degree Ref:
PHASE VOL SET Min to Max
19) HUM & NOISE ( 17Hz -17KHz Filter ) 3 5 mV
10K OHM LOAD @ INPUT
LEVEL VOL SET to Max
FREQ VOL & PHASE VOL SET to min
20) Current Consumption
UL 115 Vac @ 90W OUTPUT 1.5 1.6 A
@ IDLE .05 .07 A
CE 230 Vac @ 90W OUTPUT 0.8 1.0 A
@ IDLE .03 .04 A
UK 230 Vac @ 90W OUTPUT 0.8 1.0 A
@ IDLE .03 .04 A
