POWERED SUBWOOFER
SPECIFICATIONS
4
WOOFER SPECIFICATIONS
Rated Impedance 4 ohms +/- 0.8 at 1V 200 Hz
Voice coil DCR 3.2 +/-0.16 ohm
Sweep Test Sine Wave 6V at 20-20K Hz
Resonant Frequency (Fo) 40 +/- 8 Hz
Sensitivity 89 dB/W/m
Rated Power Input 80W
Maximum Power Input 160W
Power Test 40W Music Max/Channel
80W RMS/Channel
(The rated power is verified by performing power handling test by feeding
rated output with "IEC268-5" for 8 hours)
Main Magnet Ø90 x Ø45 x 15mm
Bucking Magnet Ø90 x Ø45 x15mm
