PI100 SERIES
49TPI10EN04 2
2. SPECIFICATIONS
MODEL PI100S PI100T
DISPLAY 15MM LCD DISPLAY WITH
WHITE LED BACK LIGHT
FRONT AND POLE: 15MM LCD
DISPLAY WITH WHITE LED
BACK LIGHT
GROSS WEIGHT 4.1KG 4.7KG
CAPACITY 3/6 KG 6/15 KG 15/30 KG
READABILITY 1/2 G 2/5 G 5/10 G
MAX. DIVISIONS 3000E/ 2X3000E
WEIGHING UNITS KG
PAN SIZE 204X263MM
HOUSING ABS PLASTIC AND STAINLESS STEEL PAN
INTERFACE RS232 OUTPUT OPTIONAL
OPERATION
TEMPERATURE
-10°C -+ 40°C / 14°F - 104°F
STABILISATION TIME 1 SECONDS TYPICAL
POWER AC ADAPTOR 12V/500MA , RECHARGEABLE BATTERY
6V/3.2AH
KEYPAD 20 KEYS
ZERO RANGE 0MV~5MV
SIGNAL INPUT RANGE 0~15MV
ADC SIGMA DELTA
INTERNAL COUNTS 600,000
ADC UPDATE MAX 60 TIMES /SECOND
LOAD CELL DRIVE
VOLTAGE
MAX 5V/150MA
