CEM DT-9929 - Technical Specifications Continued; Frequency, Duty Cycle, Temp, 4-20 mA% Specs; Accuracy Specification Notes

24
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and
<100kHz; 5Vrms min @ 20% to 80% duty cycle and >
100kHz.
Frequency
(electrical)
40.00Hz-10KHz
0.01Hz - 0.001KHz
 (0.5% reading)
Sensitivity:1Vrms
Duty Cycle
0.1 to 99.90%
0.01%
 (1.2% reading + 2 digits)
Pulse width: 100µs - 100ms, Frequency: 5Hz to 150kHz
Temp
(type-K)
-50 to 1200C
0.1C
(1.0% reading + 2.5°C)
(1.0% reading +4.5°F)
(probe accuracy not included)
-58 to 2192F
0.1F
4-20mA%
-25 to 125%
0.01%
±50 digits
0mA=-25%, 4mA=0%, 20mA=100%, 24mA=125%
Note: Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital converter.
