CEM DT-9935 - Page 16

Frequency = 10kHz
Range
200.00uH
2000.0uH
20.000mH
200.00mH
2000.0mH
20.000H
Resolution
0.01uH
0.1uH
1uH
0.01mH
0.1mH
1mH
Lx Accuracy
1.8% 10d
1.5% 10d
1.2% 10d
1.5% 15d
2.0% 10d
2.5% 15d
±
±
±
±
±
±
DF Accuracy
1.8% 50d
1.5% 50d
1.2% 50d
1.5% 50d
2.0% 50d
2.5% 50d
±
±
±
±
±
±
Measurement
Mode
Series
Series
Series
---
Parallel
Parallel
Range
20.000uH
200.00uH
2000.0uH
20.000mH
200.00mH
Resolution
0.001uH
0.01uH
0.1uH
1uH
0.01mH
Lx Accuracy
2.5% 10d
1.5% 10d
1.3% 15d
2.0% 15d
2.5% 15d
±
±
±
±
±
DF Accuracy
2.5% 50d
1.5% 50d
1.3% 50d
2.0% 50d
2.5% 50d
±
±
±
±
±
Measurement
Mode
Series
Series
Series
Parallel
Parallel
Frequency = 100kHz
Capacitance@Ta=18~28 (De)
Frequency = 100 Hz/120 Hz
O
C
Range
20.000nF
200.00nF
2000.0nF
20.000uF
200.00uF
2000.0uF
20.00mF
Resolution
1pF
0.01nF
0.1nF
1nF
0.01uF
0.1uF
0.01mF
Cx Accuracy
2.5% 10d
1.2% 10d
0.9% 10d
1.0% 15d
1.2% 10d
2.5% 10d
5.0% 10d
±
±
±
±
±
±
±
DF Accuracy
2.5% 50d
1.2% 50d
0.9% 50d
1.0% 50d
1.2% 50d
2.5% 50d
5.0% 50d
±
±
±
±
±
±
±
Measurement
Mode
Parallel
---
---
Series
Series
Series
Series
16
Dual Display LCR Meter Instruction Manual
