CEM DT-9935 User Manual

4-1 Front Panel Display Descriptions
1.LCD Display
2.Mode (Auto LCR/L/C/ACR/DCR) selection button
3.Calibration mode selection button
4.Sorting mode button
5.Secondary Display mode (for dissipation factor(D), quality
factor (Q), phase angle (θ), equivalent series resistance (ESR),
equivalent parallel resistance(Rp) measurement) selection and
the modify sorting value ( ) button
6.Test Frequency selection button
7.Relative mode and the modify sorting value ( ) button
8.Power ON/OFF button
9.Enter modify sorting value mode button
10.APO (Auto power off) button
11.Modify sorting value ( ) button
12.Confirm and select the value user need to modify in sorting
mode
13.Hold Display mode button
14.Parallel or Series measurement method selection and the
modify sorting value ( ) button
15.Back light button
16.Input sockets (banana jack inputs) and terminals for positive,
negative, and guard (see “Guard Terminal” in “SUPPLEMENTAL
INFORMATION” section for details)
7
Dual Display LCR Meter Instruction Manual

CEM DT-9935 Specifications

General

Brand	CEM
Model	DT-9935
Category	Measuring Instruments
Language	English
