Page 7For technical questions, please call 1-888-866-5797.Item 63423
SAFETYOPERATIONMAINTENANCE ASSEMBLY
Attach Wheel Assembly
1. Lay Charger down.
2. Attach Wheel Assembly with two Brackets (33)
and four Tapping Screws (29).
Tapping
Screw
Bracket
Attach Foot
1. Attach Foot (30) with four Tapping Screws (29).
Foot
Tapping
Screw
Attach Handle
1. Remove two top screws on each side of Charger.
2. Align Handle (1) with mounting holes.
3. Attach Handle with screws.
Screws
Screws
Handle
To Next Page
