Center 110 - Parts and Controls Overview; Name of Parts and Positions

4
600V 1V 1%+4 1.2%+4
10M
Ω
750Vrms
DC Current (uA,mA,Auto Range)
Range Resolution Accuracy
Burden
Voltage
Overload Protection
400uA 0.1uA 1%+2 <0.25V 0.5A / 250V Fast Blow Fuse
4000uA 1uA 1%+2 <1V 0.5A / 250V Fast Blow Fuse
40mA 10uA 1%+2 <0.25V 0.5A / 250V Fast Blow Fuse
400mA 100uA 1%+2 <1.5V 0.5A / 250V Fast Blow Fuse
10A 10mA 1.2%+2 0.35V 10A / 250V Fast Blow Fuse
AC Current(uA,mA,Auto Range)
Accuracy
Range Resolution
45Hz~500Hz 500Hz~1KHz
Burden
Voltage
Overload Protection
400uA 0.1uA 1.3%+5 1.6%+5
<0.25Vrms 0.5A / 250 Vfast Blow Fuse
4000uA 1uA 1.3%+5 1.6%+5
<1Vrms 0.5A / 250 VFast Blow Fuse
40mA 10uA 1.3%+5 1.6%+5
<0.25Vrms 0.5A / 250 VFast Blow Fuse
400mA 100uA 1.3%+5 1.6%+5
<1.5Vrms 0.5A / 250 VFast Blow Fuse
10A 10mA 1.5%+5 1.8%+5
<0.35Vrms 10A / 250V Fast Blow Fuse
Ohms ( Auto Range)
Range Resolution Accuracy Test Voltage Overload Protection
400
Ω
0.1
Ω
0.75%+2 <1.5VDC 600Vrms
4K
Ω
1
Ω
0.75%+2 <1.5VDC 600Vrms
40K
Ω
10
Ω
0.75%+2 <1.5VDC 600Vrms
400K
Ω
100
Ω
0.75%+2 <1.5VDC 600Vrms
4M
Ω
1K
Ω
0.75%+2 <1.5VDC 600Vrms
40M
Ω
10K
Ω
1.2%+3 <1.5VDC 600Vrms
Frequency ( Auto Range)
Range Resolution Accuracy Sensitivity Overload Protection
4 KHz 1Hz 0.1%+1 <300mVpp 600V rms
40KHz 10Hz 0.1%+1 <300mVpp 600V rms
400KHz 100Hz 0.1%+1 <300mVpp 600V rms
4MHz 1KHz 0.1%+1 <3Vpp 600V rms
40MHZ 10KHz 0.1%+1 <3Vpp 600V rms
