3
Weight: Approx.220g(7.76oz)
Dimensions(L×W×H):
150mm×72mm×35mm (5.9”×2.83”×1.38” )
Accessories:
Test leads, Spare fuse ( 0.5A/250V ),Batteries and Instruction manual.
1-2 Electrical Specifications
Accurace specification:±([… %of reading]+ […number of least significant
digits]) at 18℃to 28℃( 64℉to 82℉)≦80%RH
Diode Tester
Range Resolution Accuracy Test Current Test Voltage
Overload
protection
1mV 1%+ 2 <1mA <3.2V 600Vrms
Continuity beeper
Range Active Range Test Voltage Overload protection
under40
Ω
<1.5V 600Vrms
DC Voltage ( Auto Range)
Range Resolution Accuracy Input Impedance Overload Protection
400mV
0.1mV 0.5%+2
≒
200 M
Ω
750Vrms
4V 1mV 0.5%+2
11M
Ω
750Vrms
40V 10mV 0.5%+2
10M
Ω
750Vrms
400V 100mV 0.5%+2
10M
Ω
750Vrms
600V
1V 0.8%+2
10M
Ω
750Vrms
AC Voltage ( Auto Range)
Accuracy
Range Resolution
45Hz~400Hz 400Hz~1KHz
Input
Impedance
Overload
Protection
400mV 0.1mV
1%+5
(45Hz~100Hz)
