Clamp Meter
6
5. BUTTON INSTRUCTION
5-1 HOLD Function
It is possible to freeze the value displayed by pressing on the
"HOLD" button.
Press the "HOLD" button again to exit the Hold mode.
5-2 MAX/MIN Function
When the "MAX/MIN" button is pressed, the meter enter MAX/MIN
mode.
Press the button, to read MAX, MIN sequence. Press the button for
1 sec. or more to exit the MAX/MIN mode.
When you turn the rotary switch on the Continuity Test.
Press the "MAX/MIN" button to select Resistance measurement,
press the "MAX/MIN" button again to select continuity test with
buzzer.
5-3 ZERO Function
Press "ZERO" button to enter the Zero mode, ZERO Annunciate will
appear and Zero the display. The reading is stored as reference
value for subsequent measurement.
Press the " ZERO " button again, to exit the zero mode.
5-4 BACKLIGHT Function
When the "
" button is pressed, the backlight will be turned on.
To disable the function, the button is pressed again. The backlight
will be automatically turned off about 30 seconds after it turned on.
