Clamp Meter
9
6-4 DCV Measurement：
Switch the main function
selector to
range.
Connect red test lead to
“+”terminal and black one
to the “COM”terminal.
Measure the voltage by touch
the test lead tips to the test
circuit where the value of
voltage is needed.
Read the result from the LCD
panel.
6-5 Continuity Test With Buzzer：
Switch the main function to
range.
Connect red test lead to “ + ” terminal and black one to the
“COM”terminal.
Connect tip of the test leads to the points where the conduction
condition needed.
If the resistance is under 100Ω, the beeper will sound continuously.
Short circuit Open circuit
