RTD THERMOMETER
7
4.9 Low Battery Condition:
The temperature meter incorporates visual low battery indication as
follows:
Battery OK, measurements are possible.
Battery Low, battery needs to be replaced, measurements
are still possible.
Battery exhausted, the battery need to replaced with new
one(size AAA, 1.5V x 3).
5. Temperature Measurement
5.1 Correct Measurement Method:
The temperature sensor is
located at the end of the
metal sheath of the sheath
type TEMPERATURE PROBE.
To accurately test internal
temperature insert the probe
into the item you want to
measure to a distance at least
15 times the diameter of the
sheath.
5.2 Connector Configuration:
