RTD THERMOMETER
15
8. Temperature Probe
8.1 Piercing type temperature probe
8.2 Piercing type temperature probe Specification
Sensor Type
Platinum resistance thermometer
sensor Pt 100(4 wires)
Accuracy
IEC751, class A
±0.15°C±0.002t
(t: measurement temperature)
Measurement Range -100 to 400°C
Temperature Sensor
Dimensions
Approx. ∅3.2mm(∅0.125”)
Temperature Sensor
Length
Approx. 120 mm(4.72”)
Cable Length Approx. 1100 mm(43.3”)
Water-resistant
EN60529:1991
IP67
