SKU 45804 PAGE 2
E194601
* NOTE:
Recommended Blade (not included):
Item #529 - 10” M2 Molybdenum Tipped (40 Tooth) saw blade.
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions,
assembly, operating, inspection, maintenance and cleaning procedures,
parts list and assembly diagram. Keep your invoice with this manual. Write
the invoice number on the inside of the front cover. Keep this manual and
invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
Accessories Included: Fence Assembly, Blade Guard, Bottom Plate,
Mitre Guide, Push Stick, Elevation Wheel Handle, 3 Hex Wrenches (4mm,
5mm, 6mm), 2 Spanner Wrenches
ITEM DESCRIPTION
Electrical Requirements 2 HP Motor /12 Volt /60 Hz
13 Amps /3,600 RPM
Blade Size Capacity 10” Diameter / 5/8” Arbor (blade not included)
Overall Dimensions 22-3/4” W x 26” L x 15-1/2” H
Table Dimensions 26” W x 17-1/2” L
Adjustable Rip Fence Size 17-3/4” W x 1-7/8” L
Scale Measurement Increments Inches / Metric
Maximum Rip With Fence 9-1/2”
Blade Adjustments 90 Degrees to 45 Degrees
Cutting Capacity 2-7/8” at 90 Degrees
2-5/16” at 45 Degrees
Weight 32.85 Lbs.
REV 07j
