Page 2SKU 90597
SPECIFICATIONS
Item Description
Power Requirement 115 VAC, 60 Hz, 13 amps (no load: 7.4 amps
with blade); Startup amps: 27.4 amps
Motor 5200 RPM, 3 HP, 1495 Watts
Table Dimensions 19-1/2 x 7-1/4 inches; 10 inch (dia.) turntable
Table Stops Positive Stops: 0, 15, 22.5 degrees;
Miter Bevel: 30 and 45 degrees L/R
Overall Dimensions 21-3/4 x 21-3/8 x 20 inches
Saw Blade 10 inch, 60 tooth, 1 inch arbor
Blade Height 4-1/2 inches (maximum)
Power Cord 6-1/2 feet; Polarized plug
Weight 32.9 lbs.
Features Trigger switch with safety button
Electric brake
Spring retracted head assy.
Retractable Blade Cover
SAVE THIS MANUAL
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instruc-
tions listed below may result in electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
Work Area
1. Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
2. Do not operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases, or dust. Power tools create sparks which may ignite
the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.
4. Maintain a safe working environment. Keep the work area well lit. Make sure there
is adequate surrounding workspace. Always keep the work area free of obstructions,
grease, oil, trash, and other debris. Do not use a power tool in areas near flammable
chemicals, dusts, and vapors. Do not use this product in a damp or wet location.
REV 12/03
