SKU 65902/66742 For technical questions, please call 1-800-444-3353. Page 15
Air Input ON OFF Valve (4)
Pressure Gauge (6)
Media Regulator Assembly (15)
Media Flow Control Knob (16)
Safety Valve (17)
Ceramic Nozzle (21)
Bushing (13)
Air Pressure Regulator (5)
COMPONENTS AND CONTROLS
OF THE PORTABLE SODA BLASTER
Hex Nut (2)
Nozzle Coupler (20)
Storage Tank (1)
O-Ring (12)
Media Outlet Hose (19)
Media Release
ON OFF Valve (18)
Air Hose (10)
Compression Nut (22)
Quick Disconnect
Safety Valve(7)
Male Coupler (3)
Tank Bracket (23)
Socket Head Cap
Screw (8)
Bracket (9)
Air Pressure Regulator
Knob (24)
Pickup Tube (11)
not shown
ASSEMBLY DIAGRAM
Quick Release (14)
To Next Page
