Parts List and Diagram
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part Description Qty
1 Bolt M8x105 4
2
Spring Washer M8 4
3
Cylinder Head 1
4
T-Fitting 1
5
Cylinder Head Gasket 1
6
Valve Plate 1
7
Position Pin 2
8
Inlet Valve 1
9
Cylinder Upper Gasket 1
10
Piston 1
11
Cylinder 1
12
Cylinder Lower Gasket 1
13
Compression Ring 2
14
Oil Ring 1
15
Piston Pin 1
16
Circlip 12 2
17
Eccentric 1
18
Conrod 1
19
Screw M8x22-LH 1
20
Screw M5x15 6
21
Oil Sight Gauge 1
22
Oil Sight Gauge Seal 1
23
Crankcase Cover 1
24
Crankcase Cover Gasket 1
25
Motor Sets
1
25a Overloading Protector
1
26 Capacitor Fixture 1
27
Capacitor 1
28
Spring Washer M3 2
29
Screw M3x6 2
30
Inner Washer M8 1
31
Nut M8 1
32
Oil Drain Plug 1
33
Relief Valve 1
34
Fan 1
35
Circlip 14 1
36
Inner Washer M4 1
37
Screw M4x6 1
38
Oil Fill Cap 1
Part Description Qty
39
Tapping Screw St4.2x12 2
40
Bolt M5x12 2
41
Shroud 1
42
Air Filter Kit 1
43
Bolt M8x30 4
44
Washer M8 8
45 Spring Washer M8 4
46
Nut M8 6
47
Tank 1
48
Check Valve 1
49
Drain Valve 1
50
Rivet Bolt M6 4
51
Washer M6 4
52
Screw M6x20 4
53
Handle 1
54
Brass Washer 2
55
Compression Nut G3/8 2
56
Exhaust Tubing 1
57
Fin Tube 1
58
Relief Tube 1
59
Relief Nut 1
60
Pressure Switch 1
61
Strain Relief 1
62
Pressure Gauge Y50 1
63
Safety Valve 1
64
Pressure Gauge Y40 1
65
Regulator 1
66
Quick Coupler 1
67
Connect NPT 1/4X30 1
68
Connect NPT 1/4X48 1
69
Rubber Foot 2
70
Bolt M8x20 2
71
Nut M10 2
72
Spring Washer M10 2
73
Wheel 2
74
Axle 2
75
Power Cord 1
76
Cable Connector U 2
77
Cable Connector O
1
