PARTS LIST
Part Description Qty
1 Air Cap 1
2 Lock Ring 1
3 Brass Ring 1
4 Fluid Nozzle 1
5 Trigger Bolt 1
6 Gasket 1
7 Trigger 1
8 Gun Body 1
9 Pattern Valve Seat 1
10 Pattern Control Knob 1
11 Pattern Needle 1
12 Gasket 1
13 O-Ring 1
14 Needle Spring 1
15 Needle Holder 1
16 Fluid Control Knob 1
17 Needle 1
18 Needle Screw 1
19 Needle Seat 1
20 Air Inlet Coupling 1
21 Air Valve Spacer 1
22 O-Ring 1
23 Air Valve 1
24 Air Spring 1
25 Air Valve Seat 1
26 Air Valve Cap 1
27 Air Valve Screw 1
28 Fluid Inlet Coupling 1
29 Needle Guide 1
30 Needle Packing Screw 1
31 Cup (See Fig.1) 1
32 Cup Locking Lever (See Fig.1) 1
33 Cup Mounting Yoke (See Fig.1)
To Next Page
