CENTURION SYSTEMS VANTAGE 400 - V-Series Wall Box

page 16 www.CentSys.com
1. 12V 7.2Ah Battery
1
2. V-Series Controller with built-in
receiver
3. V-Series User Guide
4. V-Series Electrical Setup &
Commissioning Guide
5. Charger
6. Code-hopping remote controls
FIGURE 4. V-SERIES WALL BOX INCLUDING CHARGER AND CONTROLLER
3
4
6
1
5
2
SECTION 4 PRODUCT IDENTIFICATION
4.1. V-Series Wall Box
1. Batteries can be of a larger capacity for longer power failure autonomy and are not included in the kit;
Consult your local authorised dealer for assistance
