OPTIONS AND FEATURES
16. Auto Close
Auto Close can enhance the security of your property by ensuring that your garage door is never
unintentionally left open.
Auto Close will automatically close the garage door;
i. 3 sec after reaching the fully open position - provided that a person or object has passed through
the Safety Beams within the Delay Time, or
ii. upon expiry of the user selected delay time – provided that a person or object has not passed
through the Safety Beams within the Delay Time.
Note: Auto Close will function only when used in conjunction with Safety Beams. (Refer sec.23)
Enabling
The function select Dip Switches are contained within the rear cover of the AGDO
Select Dips 1 & 2 to the “ON” position. (Fig.11)
Delay Time Selection
Auto Close delay time may be configured according to the following table;
Delay (sec) Dip No. 3 Dip No. 4
15 off off
30 on off
45 off on
60 on on
17. Courtesy Lamp
The in built Courtesy Lamp will illuminate each time the AGDO is activated and then switch off
automatically 3 min after receiving the last Hand Transmitter or run signal.
Bulb Replacement
Remove Lamp Cover by lifting at the 2 uppermost inside edges.
Remove bulb by turning it in an anti-clockwise direction.
Replace bulb with identical 60W (maximum) Edison Screw rough construction.
Important Note: Replacing the bulb with a model greater than 60W will cause the light cover
and/or main cover to melt!
18. Dip Switches
The Dip Switches located within the back cover of the AGDO (Fig.11) enable or disable specific
functionality.
By reading through the section titled “Options and Features” the AGDO’s functionality can be
customized to individual requirements.
The functions of the Dip Switches are described in the following table;
Function Dip No. Dip Position Reference
Safety Beams (SB) - Enable 1 ON Sec.23
Auto Close (AC) - Enable 1 & 2 ON Sec.23
Auto Close Delay Time 3 & 4 Varies Sec.16
