Centurion SDO-10 - Trouble Shooting Guide; Troubleshooting Symptoms; Suggested Remedies

- 18 -
SDOPD
TROUBLE SHOOTING GUIDE
Symptom
Suggested Remedies
Reference
Page
Item
• AGDO will not function at all
• Check that AGDO is connected to power supply
~
~
• Check power point function by plugging-in an alternate appliance
~
~
• Check that AGDO is engaged to door
11
13
• Disengage AGDO from door and check for obstructions
11
12
• Door stops before reaching
• Disengage AGDO from door and check for correct spring balance
4
3
fully open position
• Check for correct Safety Obstruction Force settings (open direction)
12
15
• Check for correct open direction travel adjustment
11
14
• Disengage AGDO from door and check for obstructions
11
12
• Door stops & reverses before
• Disengage AGDO from door and check for correct spring balance
4
3
reaching fully closed position
• Check for correct Safety Obstruction Force settings (close direction)
12
15
• Check for correct Safety Beam alignment
15
24
• Door stops before reaching
• Check for correct close direction travel adjustment
11
14
fully closed position
• Door will not Safety Reverse
• Contact serviceman
~
~
• Door requires excessive force
• Check for correct Safety Obstruction Force settings (close direction)
12
15
to Safety Reverse
• Door requires excessive force
• Check for correct Safety Obstruction Force settings (open direction)
12
15
to Safety Stop
• Check function of AGDO by operating from "Run" button
15
23
• AGDO will not function from
• Check function of AGDO by learning-in a substitute Hand Transmitter
13
16
Hand Transmitter
• Re learn Hand Transmitter code into AGDO
13
16
• Replace Hand Transmitter battery
13
16
• Hand Transmitter operating
• Replace Hand Transmitter battery
13
16
range is poor
• Extended AGDO antenna
~
~
• Courtesy Lamp will not
• Replace Courtesy Lamp bulb
14
18
function
• Cannot adjust Safety
• Ensure that Safety Obstruction Force Adjustment Mode has been entered
12
15
Obstruction Force settings
• LED Indicator glows solid
• AGDO has reached fully closed position
15
21
• LED Indicator slow flashes
• AGDO has reached fully open position
15
21
• LED Indicator has extinguished
• AGDO is traveling between limits
15
21
• Door will not Auto Close
• Check for Safety Beam damage
~
~
• Check for correct Safety Beam alignment
15
24
• Check that Dip 1 & 2 have been selected to the "ON" position
14
17
• Check that connecting wires have not come loose from Safety Beams
15
24
• Check that connecting wires have not come loose AGDO terminals
15
24
• Will not Safety Reverse when
• Check that Dip 1 has been selected to the "ON" position
15
24
Safety Beams are interrupted
• Door is noisy
• Lubricate door springs with automotive wheel bearing grease
• Lubricate pivot point of door hinges with WD40
~
~
• AGDO is noisy
• Check for loose Courtesy Lamp cover is not loose
~
~
• Check that main cover is not loose
~
~
• Check that chain is correctly tensioned
7
4
