Certikin COH280 - Page 73

27
General Location of Components
Bypass Valve
Pump
Burner
Cold water
Mains inlet
Safety
Outlet
To Pool
Expansion
Vessel
Pressure switch
Fig. 7:3a
Oil Filter
& line
From Pool
18/05/06
Air Vent
Stop cock
NR Valve
Fixing Locations
Fig. 6:4a
Door
securing
screw.
Retaining Bracket
on the front of the
Flue Top.
Top
Base
One Screw
One Screw
Silicone Sealant
Fig. 6:4b
Short Flue Spigot Sealant Locations
280 Only
