Fig 8:3e
ELECTRICAL ASSEMBLY - All Models
Item Description All Models
1
High Limit Stat SPCOH015
2
Control Board SPCOH2
/
001
3
Boiler & Pool Temperature Sensor SPCOH2
/
002
4
Pressure Gauge SPCOH2
/
003
5
Control Knob (2 Places, not shown) SPMB3411
6
Stop Ring (not shown) SPMB515
7
Bypass valve (not shown) SPCOH034
8
Reset grommet (not shown) SPCOH2
/
007
9
Bypass Sensor (not shown) SPCOH2/004
23-04-03
1
2
4
3
9:2 ACCESSORIES
110 180 220 280
Standard Horizontal Balanced Flue Kit SPCOHBF1 SPCOHBF2 SPCOHBF3
Extended Horizontal Balanced Flue Kit SPCOHBF1L SPCOHBF2L
uses extensions
Terminal Guard SPCOHTG1 SPCOHTG2
Outdoor Vertical Kit SPCOHBFOV10 SPCOHBFOV11 PCOHBFOV3
Vertical Balanced Flue Adapter & Terminal SPCOHBFIV1 SPCOHBFIV2 SPCOHBFIV3
Short Vertical Balanced Flue Extension SPCOHBFV15E SPCOHBFV25E
Long Vertical Balanced Flue Extension SPCOHBFV11E SPCOHBFC21E
