43MB Pool & spa heater
Key Description - 185, 265 & 405 Models 185 265 405
B BURNER TRAY
1-B Burner Tray w/Gas Valve Natural SPMB405
Burner Tray w/Gas Valve Propane SPMB403
3-B Burner 301210 301210 301210
4-B Burner Orifi ce Natural No.50 350079 350079 350079
Burner Orifi ce Propane No.59 350350 350350 350350
C CONTROLS
1-C Thermostat Pocket, High Limit M3028 M3028 M3028
2-C High Limit 60ºC (135ºF) 006725F 006725F 006725F
3-C Control PCB SPMB2/001 SPMB2/001 SPMB2/001
5-C Temperature Sensor SPCOH2/002 SPCOH2/002 SPCOH2/002
6-C High Limit Manual Reset 102ºC M3029 M3029 M3029
G GAS VALVE
1-G Honeywell Gas Valve M3265 M3265 M3265
2-G L.P.G. Softlight Adapter M3694 M3694 M3694
H HEAT EXCHANGER (CAPRON)
1-H Heat Exchanger Assembly SPMB2/008 SPMB2/002 SPMB2/003
2-H
Inlet/Outlet Header 006706F 006706F 006706F
3-H Return Header 006707F 006707F 006707F
4-H Tube Bundle SPMB2/007 SPMB2/004 SPMB2/005
6-H Baffl e Kit SPMB118 SPMB307 SPMB407
7-H Bolt Kit 006712F 006712F 006712F
8-H Header Gasket/O Ring (2) 006713F 006713F 006713F
9-H Unitherm Governor 006719F 006719F 006719F
11-H Bypass Valve SPMB125 SPMB125 SPMB125
12-H Bypass Spring 850293 850293 850293
14-H Sensor Well, Pool Temperature 066899 066899 066899
15-H Well Retaining Clip SPMB100 SPMB100 SPMB100
16-H Inlet & Outlet Flange Unions inc' O rings SPMB2/010 SPMB2/010 SPMB2/010
17-H Flange O Rings (2 sets) 006724F 006724F 006724F
18-H Drain Plug 006721F 006721F 006721F
H HEAT EXCHANGER (CAST IRON)
1-H Heat Exchanger Assembly SPMB601 SPMB301 SPMB404
2-H Inlet/Outlet Header SPMB130 SPMB130 SPMB130
3-H Return Header SPMB3405 SPMB3405 SPMB3405
4-H Tube Bundle SPMBTA185 SPMBTA265 SPMBTA405
6-H Baffl e Kit SPMB118 SPMB307 SPMB407
7-H Bolt Kit SPMB520/S SPMB520/S SPMB520/S
8-H Header Gasket/O Ring (2) SPMB13402 SPMB13402 SPMB13402
9-H Unitherm Governor SPMB508C SPMB508C SPMB508C
11-H Bypass Valve SPMB510 SPMB510 SPMB510
12-H Bypass Spring SPMB1204 SPMB2301 SPMB2301
13-H Drain Valve SPMB723 SPMB723 SPMB723
14-H Sensor Well, Pool Temperature SPMB511 SPMB511 SPMB511
15-H Well Retaining Clip SPMB100 SPMB100 SPMB100
16-H Inlet & Outlet Flange SPMB23401 SPMB23401 SPMB23401
17-H Flange Gasket SPMB3404 SPMB3404 SPMB3404
18-H Drain Plug SPMB517 SPMB517 SPMB517
J J BOX/CONTROL BOX
1-J Ignition Control, Robershaw SPMB502 SPMB502 SPMB502
2-J Transformer 230V/24V M650531 M650531 M650531
4-J Rocker Switch AH0050 AH0050 AH0050
Parts list is continued on next page »»»»»»»»»»
