© Cesab 5 – 40 T Code(s): 841, 842, 843
Repair manual: Parameters Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Basic option 15 – Activate restrictions on hydraulics via SEU inputs
Argument #1
Selection of SEU unit 1 or 2
Values Meaning
0 option is handled by SEU unit 1 [A36]
1 option is handled by SEU unit 2 (the second SEU unit)
Argument #2
Selection of SEU digital input
Values Meaning Pin no.
0 activates digital input 1 (1 mA) on SEU 5
1 activates digital input 2 (1 mA) on SEU 19
2 activates digital input 3 (1 mA) on SEU 33
3 activates digital input 4 (1 mA) on SEU 6
4 activates digital input 5 (7 mA) on SEU 20
5 activates digital input 6 (7 mA) on SEU 34
6 activates digital input 7 (7 mA) on SEU 7
7 activates digital input 8 (7 mA) on SEU 21
Argument #3
Connecting restrictions. The values in argument #3 can be combined
through addition, e.g. value 1 + value 8 = value 9
Values Meaning
1 Block the lift/pressurising of hydraulic function 1
2 Block the lowering/depressurising of hydraulic function 1
4 Block the lift/pressurising of hydraulic function 2
8 Block the lowering/depressurising of hydraulic function 2
16 Block the lift/pressurising of hydraulic function 3
32 Block the lowering/depressurising of hydraulic function 3
64 Block the lift/pressurising of hydraulic function 4
128 Block the lowering/depressurising of hydraulic function 4
Argument #4
Override switch
Values Meaning
0 Option switch 2 or 5 gets the override function
1 Option switch 1 gets the override function
2 Option switch 2 gets the override function
3 Option switch 3 gets the override function
4 Option switch 4 gets the override function
5 Option switch 5 gets the override function
6 Option switch 6 gets the override function
7 Option switch 3 or 4 gets the override function
8 No override possible
