265 Shannon Lane
Priest River ID 83856
TITLE: Supplemental Airplane Flight Manual
A-10060
03/04/15
Cessna 206 on Model 3400 Floats
REVISION: D
FAA Approved
SECTION 7. AIRPLANE AND SYSTEMS DESCRIPTIONS:
In addition to the Aerocet 3400 amphibious seaplane float installation the
aircraft must incorporate the Cessna approved seaplane kit and an approved
three blade propeller according to the STC. As a result of these
installations, the floatplane is identical to the landplane with the following
exceptions:
CHANGE FROM LANDPLANE TO AMPHIBIOUS SEAPLANE
Installation of Aerocet amphibious floats include the following
modifications or additions to a landplane. This is an overview. The
complete information resides in Cessna manuals, Aerocet drawings and the
STC.
Cessna Float Kit Modifications to Airplane
1. Fuselage strengthening installed at factory.
2. V-brace. Hoisting rings. (installed at factory or later)
3. Aileron Fences. (also available from Aerocet)
4. Empennage changes: Vertical fin and beacon modified, ventral fin,
rudder, fairings, stinger, dual tail tie-down rings.
5. Rudder trim bungee replaced with softer.
6. Water rudder bellcranks.
7. Cowl flap rod extensions on models A through G.
8. Exhaust extensions on models A through G.
Aerocet Float Installation
9. Float undercarriage: float hulls, spreader bars, struts, flying wires,
boarding steps, water rudder rigging, retractable landing gear system.
10. Hydraulic lines, reservoir and pump with associated electrical wiring for
landing gear operation.
11. Propeller listed in Section 1 of this AFMS.
12. Exhaust pipe modification on H-model
13. Wing mounted mirrors.
14. In cockpit:
- Gear selector with light and audio advisories
- Placards
- Emergency hand pump handle
- Water rudder retraction handle
Adjustments for Seaplane
15. Elevator trim rigging changed
16. Flap travel limited to 30 deg
