- 77 -
Adjustment
● Turn throttle grip after installed cable.
●
Tighten the lock nut.
●
Adjust screw position.
●
Loosen the lock nut and adjust it until a play of 2mm~3mm is obtained at the throttle grip.
●
Tighten the lock nut.
CAU
TION
Operation
with improperly adjusted, incorrectly routed, or damaged cables could result in an
unsafe riding condition.
Idle Speed
The idle spe
ed of the vehicle ha
s
been adjusted before the vehicle out of factory. There is no need to do any
adjustment by yourself, otherwise vehicle’s performance will be affected. If there is any parts which will affect idle
speed need to be replaced, contact with authorized local dealer and use PDA to diagnose and have calibration.
CAUTION
Improperly adjustment
of idle speed could result in an unsafe riding condition.
Idle Speed：1500r/min±150r/min
