78 Chadwick-Helmuth Company, Inc.
Chapter 5 - General Operation
NOTE: If, at any time, the user wants to stop collecting data, press
the
GO BACK
key while the Data Collection screen displays.
Vibrex unit then displays a Measurements screen that reads out the
acquired balance measurements (see below).
4. If one or more readings become suspect for any reason, the user may
retake a reading by pressing the
REDO MEAS
context key. This
action automatically erases the former reading.
CAUTION: Pressing
GO BACK
cancels (undoes or erases) the
measurement.
5. If the current reading is correct, press
START to advance to the next
screen.
NOTE: High-horsepower, coarse pitch propellers may stall at a
maximum static RPM. Do not attempt a balance with the propeller
stalling, because the resulting balance reading in this situation is
inaccurate. A propeller is stalling if there is a noticeable change in
the propeller’s sound, from what the user normally hears.
RUN 1 PROP MEAS
08APR00 09:31:08 #1A
[ANNOTATE ]
480 RPM
0.15 IPS @ 7:29
ID: -1
REDO MEAS
solution push START
USE TO ENTER
NOTES TO ONE’S
SELF
RPM (AZIMUTH),
IPS (VIBRATION),
AND PHASE
MEASUREMENTS
SELECT TO START THE RUN
OVER AND RETAKE A
MEASUREMENT
DATE, TIME, AND
CHANNEL
NUMBER
To Next Page
