CHAINTECH 7VJL1 - Chapter 1 Introduction; 1-1 Product Specifications

Chapter 1
1
Chapter 1 Introduction
1-1 Product Specifications
Processor
- Supports AMD Socket A Duron / Athlon / XP processors.
- System Clock supports 200 / 266 MHz Front Side Bus
Chipset
- VIA® KT266A + VT8235 Chipset.
Main Memory
- Supports three 184-pin DDR DIMM sockets up to 3GB.
- Supports PC1600/DDR200 PC2100/DDR266 DDR SDRAM modules.
Expansion Slots
- One Universal - AGP slot for both 2X / 4X AGP (V2.0 compliant).
- Six 32 - bit PCI slots (v 2.2 compliant).
Audio subsystem via AC-Link
- With external high quality AC'97 Codec
- Complete software driver supports for Windows® OS
Embedded Ultra DMA - 133 PCI IDE controller
- Supports two IDE ports up to 4 ATAPI devices
- Supports up to PIO Mode 4 up to 16.6MBps, Multi Mode 4 up to 66MBps, Multi
Word Mode 5 up to 100MBps and Multi Word Mode 6 up to 133MBps with bus
mastering
- Bus Mastering software drivers for common multi-task operating systems
Embedded USB 2.0/1.0 Host Controller
- UHCI compliant USB host controller with Root hub
- Six USB ports (EHCI/UHCI v1.1 compliant) with over current protection.
- Optional USB adapter for additional USB2.0/1.1 ports
On board ITE 8705 Super I/O Controller
- Two UARTs support serial port s and IR function (up to 115.2Kbps) for HPSIR
and ASKIR
- One SPP/ECP/EPP parallel port
- One floppy disk drive connector supports up to 2.88MB
-
Integrates smart card reader function and interface, to be qualified for meeting
PC/SC standard
Chapter 1
2
Embedded System Monitor Hardware
- 8 external voltage inputs
- 2 temperature sensor with thermistor for CPU and System
- 2 Fan speed monitoring with ON/OFF control in suspend
Ethernet 10/100 Controller
- On board PHY LAN VIA® VT6103 support 10/100Mbs operation
Boot-Block Flash ROM
- Award system BIOS support PnP, APM, DMI, ACPI, & Multi-device booting
features.
1-2 Package Contents
This product comes with the following components:
1. Motherboard x 1
2. 40-Pin UDMA-100 IDE Cable x 1
Blue
to motherboard,
Gray
to Master and
Black
to Slave.
3. 34-Pin floppy Disk Drive Cable x 1
4. Manual x 1
5. Driver CD x 1
Includes:
- Award DMI Utility for DOS
- Audio drives and utility
- LAN Drivers
- USB 2.0 Drivers
- VIA® Chipset Software installation utility.
6. Value-pack 2002 x 1
Includes:
- Norton AntiVirus
- Adobe ActiveShare
- AcobarReader
- Acobate eBook Reader
- Imagemore
- AutoSave.
