Chamberlain 248730DM - Hardware Identification; Assembly Hardware; Installation Hardware

Nut 5/16" - 18 (4)
Clevis Pin
5/16" x 1-1/2" (1)
Drywall
Anchors (2)
Rope
Ring
Fastener (3)
Lock Washer
5/16" (7)
Lag Screw
5/16"-18 x 1-7/8" (2)
Wing Nut
1/4 x 20 (2)
Insulated
Staples (30)
Rail Grease
Hex Bolt
5/16"- 18 x 7/8" (4)
Carriage Bolts
1/4"-20 x 1/2" (2)
Lag Screw
5/16"- 9 x 1-5/8" (2)
Clevis Pin
5/16" x 1-1/4" (1)
Self-Threading Screw
1/4"-14 x 5/8" (2)
2-Conductor Bell Wire
White & White/Red
Screw
6AB x 1-1/4" (2)
Screw 6-32 x 1" (2)
Spacer (2)
Clevis Pin
5/16" x 1" (1)
C21
NOTICE
Handle (not shown
actual size)
C20
C2
C3
C4
C5
C6
C7
C11
C8 C9
C10
C1
C14
C16
C17
C12
C13
C18
C19
C15
5
Threaded
Trolley Shaft (1)
Idler Bolt (1)
B5
B1
Nut 3/8" (1)
Bolt 1/4" - 20 x 1-3/4" (2)
B6
B7
Lock Washer
3/8" (1)
Lock Nut
1/2" - 20 (2)
B2
B3
Master Link (2)
B4
ASSEMBLY HARDWARE
INSTALLATION HARDWARE
