19
Installation
STEP 6 Attach the Emergency Release Rope and Handle
To prevent possible SERIOUS INJURY or DEATH from a falling garage door:
l If possible, use emergency release handle to disengage trolley ONLY when garage door is CLOSED.
Weak or broken springs or unbalanced door could result in an open door falling rapidly and/or
unexpectedly.
l NEVER use emergency release handle unless garage doorway is clear of persons and obstructions.
l NEVER use handle to pull door open or closed. If rope knot becomes untied, you could fall.
1. Insert one end of the emergency release rope through the handle. Make sure that “NOTICE is right
side up. Secure with an overhand knot at least 1" (2.5 cm) from the end of the rope to prevent
slipping.
2. Insert the other end of the emergency release rope through the hole in the trolley release arm.
Mount the emergency release within reach, but at least 6 feet (1.83m) above floor, avoiding contact
with vehicles to prevent accidental release and secure with an overhand knot.
NOTE: If it is necessary to cut the emergency release rope, seal the cut end with a match or lighter to prevent
unraveling. Ensure the emergency release rope and handle are above the top of all vehicles to avoid
entanglement.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Chamberlain BILT B4643T and is the answer not in the manual?

Chamberlain BILT B4643T Specifications

General IconGeneral
Drive TypeBelt Drive
Horsepower1/2 HP
Battery BackupYes
Smartphone ControlYes
ConnectivityWi-Fi
Remote Controls Included2
Safety and Security FeaturesRolling Code
Speed7.0 in/sec
MotorDC
Warranty5 years on parts
LightingDual LED lighting
