33
SERVICE KITS
ITEM PART # DESCRIPTION
K1 K75-12584 Brake kit - 115 Volt models
K75-12585 Brake kit - 230-460 Volt models
K75-12586 Brake kit - 575 Volt models
Complete with: Brake hub kit, brake
release lever, brake disc, spring cup,
studs, compression springs, brake
solenoid, solenoid cover, spacers,
mounting plate, pressure plate, feather
key and fastener.
K2 K75-10177 Brake hub kit
Complete with: Brake hub, set screw,
push on fastener and feather key.
K3 K72-12789 Hand chain shaft kit (1/2 thru 2HP)
Complete with: Bevel gear 5/8" ID, bevel
gear 3/4" ID, hand chain guide, hand
chain shaft, bearing 3/4" ID, nyliner
bearing, compression spring, chain wheel,
washers, roll pins and e-rings.
K4 K75-30737 Disconnect kit
Complete with: Disconnect lever, bevel
gear yoke, brake release, disconnect
shaft, tension spring, sash chain with
keyring, screws, nuts, flatwashers,
lockwashers, switch assembly GH
Interlock, actuator, square rod bushing,
#10-32 x 1/2" serrated fl. screw,
cotterpins and roll pin.
K5 K75-12829 Gear housing kit - 1HP, 115 Volts
K75-12830 Gear housing kit - 1HP, 230-460 Volts
K75-12831 Gear housing kit - 1HP, 575 Volts
K75-12832 Gear housing kit - 1.5-2HP, 230-460 Volts
K75-12833 Gear housing kit - 1.5-2HP, 575 Volts
Complete with: Housing support bracket,
pads and pressure plate, housing with
cover, disconnect kit, hand chain shaft
and brake kit.
INDIVIDUAL PARTS
ITEM PART # DESCRIPTION
1 22-120 Brake solenoid, 115V
22-240 Brake solenoid, 230-460V
22-575-1 Brake solenoid, 575V
2 80-14414 Feather key
3 32-11009 Gear reducer (1/2 thru 1 HP, 45:1)
32-11010 Gear reducer (1.5 thru 2HP, 44:1)
32-11011 Gear reducer (3HP, 42:1)
4 15-48B18LGE Sprocket, 48B18 LGE (1/2 thru 1HP)
15-48B18PJH Sprocket, 48B18 PJH (1-1/2 thru 2 HP)
15-48B18QGH Sprocket,48B18 (3HP)
5 15-50B12LGH Sprocket, 50B12 LGH (1/2 thru 1HP
15-50B12PJH Sprocket, 50B12 PJH (1-1/2 thru 2 HP)
15-80B9QGH Sprocket,80B9 (3HP)
6 10-11021 Disconnect lever
7 19-8A-12 Sash chain 12' with keyring
8 08-11012 Bevel gear, 5/8" ID
75-13334 Bevel gear, 3/4" I.D. (3 HP)
9 08-11013 Bevel gear, 3/4" I.D.
08-13333 Bevel gear, 3/4" I.D. 24 tooth (3 HP)
10 10-10882 Hand chain guide
11 12-10883 Nyliner bearing
12 11-11105 Hand chain shaft
13 12-10029 Bearing, 3/4" I.D.
14 18-11008 Compression spring
15 75-10884 Chain wheel assembly
16 K20-1050C-2LP Motor - models GH5011L3, GH5021L3
K20-3050C-4P Motor - models GH5023L3, GH5043L3
K20-3050M-5 Motor - model GH5053L3
K20-1075C-2LP Motor - models GH7511L3, GH7521L3
K20-3075C-4P Motor - models GH7523L3, GH7543L3
K20-3075M-5 Motor - model GH7553L3
K20-1100C-2LP Motor - models GH1011L3, GH1021L3
K20-3100C-4P Motor - models GH1023L3, GH1043L3
K20-3100M-5 Motor - model GH1053L3
K20-1150C-2LP Motor - models GH1511L3, GH1521L3
K20-3200C-4P Motor - models GH1523L3, GH1543L3
K20-3200C-4P Motor - models GH2023L3, GH2043L3
K20-3300C-4 Motor - models GH3023L3, GH3043L3
17 74-30731 Switch assembly GH Interlock
18 10-19593 Actuator (For Standard GH Operators)
10-19593-1 Actuator (For Nema 4 GH Operators)
19 82-WX10-08T #10-32 x 1/2" Serrated Fl. Screw
20 13-19510 Square rod bushing
NOT SHOWN
01-19460 Owner’s Manual - English
01-19460SP Owner’s Manual - Spanish
01-19460FR Owner’s Manual - French
REPAIR PARTS KITS - MODEL GH
