en-14
Indication Description Remedy
1x blinking Motor 1 has insufficient connection to control board Green or white cable not wired or badly connected Check
terminals precisely. Consider wire lengths
2x blinking Motor 2 has insufficient connection to control board Refer to 1x blinking
3x blinking Limits for motor 2 have not been accepted A: Open gate wide enough when programming the travel (50%
A: After or during programming travel: Wing 1 did not over maximum)
open wide enough and did not meet the integrated B: Check terminals precisely. Consider wire lengths
passpoint which is located inside the operator halfway
above the spindle.
B: Motorcables have insufficient connection to contol board
Yellow or white cable not wired or badly connected
4x blinking Limits for motor 1 have not been accepted Refer to 3x blinking
5x blinking Travel has not been programmed Repeat programming travel
The process of programming has been interrupted
6x blinking Force to operate the gate is too high
A: Gate is out of order A: Repair gate
B: Gate is rough-running B: Check if gate can be easily moved
C: Gate stopped through windload C: Do not operate gate by windstorm
D: Reprogram travel to achieve sufficient level of fo
7x blinking Photocells 1 block installation
A: Object blocks photocells A: Remove object
B: Alignment of the lenses is incorrect B: Check alignment
C: Power supply to photocells is insufficient C: Check cable widths and contacts
8x blinking Photocells 2 block installation Refer to 7x blinking
9x blinking Emergency stop switch blocks installation A: Check wiring
B: Check basic setting of control board (Jumpers)
10xblinking Safety edge blocks installation
A: Object obstructs safety edge A: Remove object
B: Defective safety edge B: Check wiring. Check resistor 8.2KOhms
C: Power too low or broken wire in supply C: Check basic setting of control board (Jumpers)
11xblinking Power supply to control board is too low
A: Defective supply 230V or malfunctioning contact A: Check electric contact
B: Broken wire in supply cable (copper cable) B: Check by electrician
C: The battery (accessory) to operate the gate whilst C: Allow battery to charge 24 hours
power failure is dead.
12xblinking EEPROM Fault
Power up failed Replace contol board
INDICATION OF THE DIAGNOSIS LED
