Chamberlain SL585 - REPAIR PARTS AND ILLUSTRATED GUIDES

32
ΡΕΠΑΙΡ ΠΑΡΤΣ − ΜΟ∆ΕΛ ΣΛ585
SERVICE KITS
ITEM PART # DESCRIPTION
K1 71-B120 Brake kit - 115 Volt models
71-B240 Brake kit - 230-460 Volt models
71-B575 Brake kit - 575 Volt models
Complete with: Brake hub kit, brake
release lever, brake disk, spring cup,
studs, compression springs, brake
solenoid, solenoid cover, spacers,
mounting plate, pressure plate, feather
key and conduit.
K2 K75-10177 Brake hub kit
Complete with: Brake hub, set screw,
push on fastener and feather key.
K3 K75-34828 Idler shaft kit
Complete with: Bearings, sprocket
50B12x1" and idler shaft
K4 K75-34824 Chain guard kit
Complete with: Chain guard, chain
guides and retainers.
K5 K75-34842 Cover kit
Complete with: Cover, lock bar and
label.
K6 K75-34790 Disconnect kit
Complete with: Release lever, bracket,
cable, compression spring, washer,
screws, clevis pin, bushings, roll pins,
bolts, nuts, and handle.
K7 K75-34791 Clutch kit
Complete with: Clutch disk, clutch
plate, hub, torque limiter, e-rings,
washers, sprocket, bearing, nut and
compression spring.
K8 K29-32410 Alarm kit
Complete with: Alarm, spacer and
faston.
K9 K75-18493 Chain guide kit
K10 653509 Optional diagonal brace kit
NOT SHOWN
71-6532449 Heater kits (Optional) -
115/230V single phase
71-6532448 Heater kits (Optional) - All 3 phase
K50-18423 Replacement heater with
thermostat only
INDIVIDUAL PARTS
ITEM PART # DESCRIPTION
1 22-120 Brake solenoid, 115V
22-240 Brake solenoid, 230-460V
22-575-1 Brake solenoid, 575V
2 80-14414 Feather key
3 12-4164 Bearing
4 15-50B12LGH Sprocket, 50B12 x 1"
5 10-30678 Lock bar
6 23-34815 Stop/Reset button
7 32-34792 Gear reducer (30:1)
8 39-13941 Clutch disk
9 K20-1050C-2P Motor - models SL585-50-11,
SL585-50-21, SL585-50-81
K20-3050C-4P Motor - models SL585-50-23,
SL585-50-43, SL585-50-83
K20-3050M-5 Motor - model SL585-50-53
K20-1100C-2P Motor - models SL585-100-11,
SL585-100-21, SL585-100-81
K20-3100C-4P Motor - models SL585-100-23,
SL585-100-43, SL585-100-83
K20-3100M-5 Motor - model SL585-100-53
VARIABLE PARTS
10 23-20088 On/off switch - 1 phase 115V
23-3001 On/off switch - 1 phase 208/230V
23-3005 On/off switch - 3 phase
NOT SHOWN
Gate bracket
Take up bolt
Chain
Bolt - 14"
01-34850 Owner’s manual - English
01-34850SP Owner’s manual - Spanish
01-34850FR Owner’s manual - French
