GB-3
INITIAL OPERATION
Check gate functionality manually when the drive has been
disengaged. Electrical operation is only possible with the control unit
that is supplied as standard.
Electrical connections: See control unit instructions.
Always ensure that the mechanical and electrical safety requirements
relevant to the given system are complied with. fig. 10
MAINTENANCE WORK
The drive mechanics are maintenance-free. Check at regular
intervals (monthly) that the gate hardware and the drive are all firmly
in place. Disengage the drive and check gate functionality. Only an
easy-running gate will work well with a drive. A drive is no substitute
for a poorly functioning gate.
A sliding gate can also be secured by implementing on-site
measures (fence, wall, etc.). See fig. 11.
TECHNICAL DATA
Voltage IN
Frequency
Power
Current rated
Torque
Capacitor
Therminal Overload
Protection
Motor Speed
Travel Speed
Duty Cycle
Working Temperatur
Range
Protection Class
Degree of Protection
Weight
approx. Gate Length
Max. Gate weight at
max. length (incl.
20% reserve)
SLY300
230Volt
50Hz
300W
1.3A
9Nm
8μF
140°
1400
12
30
-20
O
C - 55
O
C
IP44
I
9
5m
300kg
SLY500
230Volt
50Hz
360W
1.5A
10Nm
10μF
140°
1400
12
30
-20
O
C - 55
O
C
IP44
I
9
8m
500kg
SLY1000
230Volt
50Hz
480W
2.1A
12Nm
16μF
140°
1400
11.5
30
-20
O
C - 55
O
C
IP44
I
10
10m
1000kg
709269E-GB - 11.2005 © Chamberlain GmbH 2005
Declaration of Conformity
Automatic Gate Opener Models SLY300/E/K, SLY500/E/K, SLY1000/E/K Series
are in conformity to the applicable
sections of StandardsEN300220-3 • EN55014 • EN61000-3 • EN60555, EN60335-1 • ETS
300 683 • EN60335-1: 2002 • EN60335-2-103: 2003 • EN55014-1: 2000 + A1 + A2 •
EN55014-2: 2001 • EN61000-3-2: 2000 • EN61000-3-3: 1995 + A1 • EN 301 489-3,
V1.3.1 • EN 300 220-3 V1.1.1 • EN13241-1
per the provisions & all amendments
of the EU Directives ..................................................73/23/EEC, 89/336EEC, 1999/5/EG
Declaration of Incorporation
Automatic Gate Opener Models , when installed and maintained according to all the
Manufacturer’s instructions in combination with a Gate, which has also been installed and
maintained according to all the Manufacturer’s instructions, meets the provisions of EU
Directive 89/392/EEC and all amendments.
I, the undersigned, hereby declare that the equipment
specified above and any accessory listed in the manual
conforms to the above Directives and Standards.
B.P.Kelkhoff
Manager, Regulatory Affairs
Chamberlain GmbH
D-66793 Saarwellingen
October, 2005
