Crankcase/ Gear Assy/ Governor
Ref # Part # Description Qty.
1 CH78316 CRANKCASE SUBASSEMBLY 1
2 CH78317 SENSOR, ENGINE OIL 1
3 FX200-003 GEAR ASSY, GOVERNOR FX200 1
4 CH78319 BOLT 2
5 CH78320 PIN 1
6 CH78321 WASHER 1
7 CH78322 ARM, GOVERNOR 1
8 CH78323 BOLT, DRAIN PLUG 2
9 CH78324 WASHER 2
10 CH78325 OIL SEAL 1
11 CH78326 BEARING 1
