SPECIFICATION
MODEL FX200 (E)
Bore x Stroke (MM) 68X54
Displacement (CC) 196
Compression Ratio 8.7:1
Net Power (Kw/Rpm) 4.1/3600
Net Torque (N.m/Rpm) 11/2500
PTO shaft rotation Counter Clock wise
Ignition system Transistorized magneto ignition
Lubrication system Forced splash
Carburetor Flat suction valve carburetor
Governor system Centrifugal mechanical
Engine Type Forced air-cooling 4 stroke, OHV
Starting system Recoil/Electric start
Fuel Tank Capacity (L) 3.6
Engine Oil Capacity (L) 0.55
Fuel Consumption (g/Kw.h) ≤380
Dimension (LxWxH MM) 390x320x345
Net Weight (Kg) 15/17
