Throttle Control Assembly
Ref # Part # Description Qty.
1 CH78393 THROTTLE CONTROL ASSY 1
2 CH78394 SPRING, GOVERNOR 1
3 CH78395 ROD, GOVERNOR 1
4 FX200-004 THROTTLE RETURN SPRING 1
5 CH78397 SUPPORT SUBASSEMBLY, GOVER-
NOR
1
6 CH78398 BOLT 2
7 CH78399 BOLT, GOVERNOR SUPPORT 1
8 CH78400 NUT 1
30
