100554 - 3500W WIRELESS START GENERATOR
SPECIFICATIONS
31
# Part Number Description Qty.
1 100011261-0002
Flange Bolt M6 × 12,
Black Zinc
4
2 100095516-0001 Panel Assembly 1
3 100021441
Remote Control
Assembly
1
4 100019771-0001 Switch 1
5 100096134-0001 Battery Switch 1
6 100095896 Control Panel 1
7 100095927 Intelligauge, VFT 1
8 100019751
30Amp Circuit Breaker,
Push Button
1
9 100019754
20Amp Circuit Breaker,
Push Button
1
10 100120180 Breaker Cover 2
11 100020005 Receptacle L5-30R 1
12 100020008 Receptacle TT-30R 1
13 100020029
Receptacle 5-20R,
Duplex
1
14 100021446 Learning Button 1
15 100021445 Remote Indicator 1
16 100020100 Protect Panel 1
17 100098921
Receptacle Cover
5-20R, Duplex
1
18 100088268
Receptacle Cover
TT-30R
1
19 100088269
Receptacle Cover
L5-30R
1
20 100041170-0001 Roll Pin Ø16 × 85 2
21 100092300-0001 8 In. Wheel, Black 2
22 100023414-0001 R-pin 2
23 100095517-0001
Frame
590 × 464 × 505.5
1
24 100021153 Fuel Valve 1
25 100005138 Clamp Ø9.5 × 8 1
26 100095592-0001
Fuel Tank, 17.8 L,
Yellow
1
27 100093333 Fuel Tank Cap 1
28 100098838 Fuel Filter 1
29 100099571 Reversal Valve 1
30 100095894 Gauge, Fuel Level 1
31 100059920-0001
Label, Fuel Level
Gauge
1
32 100021118
Bushing,
Ø12 × Ø9 × 13
4
# Part Number Description Qty.
33 100032369
Vibration Mounting,
Fuel Tank
4
34 100010439-0001
Washer
Ø6.5 × 2 × Ø25, Black
4
35 100011268-0002
Flange Bolt M6 × 25,
Black
5
36 100009075 Rubber Damper 3
37 100010828-0002 Butterfly Type Nut M6 1
38 100099572-0001 Pressing Plate, Battery 1
39 100122390 Battery, 12V 9Ah 1
40 100009990-0001 Negative Wire 1
41 100095628 Positive Wire 1
42 100009983
Grounding Line
150 mm
1
43 100011421-0003 Flange Nut M6 1
44 100010920-0002 Flat Washer Ø6 2
45 100011025-0001
Lock Washer Ø6,
Toothed
1
46 100010886-0004 Spring Washer Ø6 2
47 100011453-0003 Lock Nut M8, Flange 10
48 100020978-0001 Support Leg Assembly 1
49 100011452-0003 Lock Nut M6, Flange 2
50 100020659-0001 Support Leg 1
51 100021015 Vibration Mount 2
52 100011265-0003 Flange Bolt M6 × 18 4
53 100011311-0005 Flange Bolt M8 × 16 2
54 100023415-0001 R-pin, R5 1
55 100011047-0003 Roll Pin Ø8 × 40 1
56 100086540-0001 Handle Assembly 1
57 100095941-0001 Handle 1
58 100031982 Sheath, Handle 1
59 100011250-0002 Flange Bolt M5 × 14 2
60 100018658-0023
Generator End Cover,
Yellow
1
61 100011252-0001 Flange Bolt M5 × 18 6
62 100095626 AVR 1
63 100018592
Carbon Brush
Assembly
1
64 100018701 Terminal Block 1
65 100010885-0004 Spring Washer Ø5 1
66 100010919-0002 Flat Washer Ø5 1
67 100011297-0002 Flange Bolt M6 × 165 4
68 100018567 End Housing 1
69 100020986-0001
Vibration Mount,
Support 1
2
Parts List
