Champion 100554 - Engine Parts List

100554 - 3500W WIRELESS START GENERATOR
SPECIFICATIONS
34
# Part Number Description Qty.
1 100011264-0003
Flange Bolt M6 × 16,
GB5789
5
2 100002335
Cylinder Head
Cover(Cpe)
1
3 100031972 Breather Tube 1
4 100066138
Gasket, Cylinder Head
Cover
1
5 100011463-0002 Flange Nut M6 2
6 100004431 Rocker Arm Assembly 2
7 100004512 Shaft, Rocker Arm 1
8 100004506 Retainer, Rocker Arm 1
9 100004505 Bolt, Rocker Arm 2
10 100004478 Guide Plate, Push Rod 1
11 100004588
Valve Adjust Cap,
Exhaust
2
12 100004585
Valve Spring Seat,
Exhaust
2
13 100004564 Spring, Valve 2
14 100004600 Oil Seal, Valve 1
15 100002464-0001 Flange Bolt M8 × 60 4
16 100002389 Cylinder Head 1
17 100009378 Spark Plug F6RTC 1
18 100010389 Stud Bolt M8 × 35 2
19 100010354 Stud Bolt M6 × 96 2
20 100092295 Gasket, Insulator 1
21 100005599 Insulator, Carburetor 1
22 100078606 Gasket, Carburetor 1
23 100094371 Carburetor 1
24 100052404 Spring 1
25 100007579
Clamp, Stepping Motor
Guide
1
26 100066136 Gasket, Air Filter Base 2
27 100051029-0001 Screw M4 × 6 4
28 100074044 Protection Cover 1
29 100061511 Stepping Motor 1
30 100095804 Mounting Bracing Plate 1
31 100004745 Air Filter Assembly 1
32 100005023 Air Filter Base 1
33 100004894 Air Filter Clip 2
34 100004877 Air Filter Separator 1
35 100011250-0002 Flange Bolt M5 × 14 6
36 100004795 Gasket, Air Filter Cover 1
37 100004770 Air Filter Element 1
38 100004873 Air Filter Cover 1
# Part Number Description Qty.
39 100011452-0003 Lock Nut M6, Flange 2
40 100007111 Air Guide, Lower 1
41 100011261-0004
Flange Bolt M6 × 12,
GB5789
6
42 100010213 Gasket, Cylinder Head 1
43 100010558 Dowel Pin Ø10 × 16 2
44 100004408 Push Rod 2
45 100004550 Valve, Exhaust 1
46 100004524 Valve, Intake 1
47 100004263 Lifter, Valve 2
48 100003245 Piston Ring Set 1
49 100003150 1st Piston Ring 1
50 100003191 2nd Piston Ring 1
51 100003283 Oil Ring 1
52 100003221 Circlip, Wrist Pin 2
53 100003081 Piston 1
54 100003125 Wrist Pin 1
55 100003448 Connecting Rod 1
56 100003430 Bolt, Connecting Rod 2
57 100002664 Crankcase 1
58 100010787 Bearing TM6205 - P63 2
59 100003770 Crankshaft 1
60 100092356 Camshaft 1
61 100010025 Oil Level Sensor 1
62 100011217-0002 Flange Bolt M6 × 16 2
63 100010544 Dowel Pin Ø7 × 14 1
64 100010554 Dowel Pin Ø9 × 14 1
65 100092294
Gasket, Crankcase
Cover
1
66 100002990 Cover, Crankcase 1
67 100017651
Oil Seal
Ø25 × Ø41.25 × 6
1
68 100011319-0001 Flange Bolt M8 × 32 6
69 100004107-0001 Oil Dipstick Assembly 1
70 100008296 Gear, Governor 1
71 100011215-0001 Flange Bolt M6 × 12 4
72 100008186 Control Assembly 1
73 100007840 Spring, Governor 1
74 100007947 Rod, Governor 1
75 100007920 Spring, Throttle Return 1
76 100008417 Arm, Governor 1
77 100007986 Cotter, Governor Shaft 1
78 100017630 Oil Seal Ø6 × Ø11 × 4 1
Engine Parts List
