100554 - 3500W WIRELESS START GENERATOR
SPECIFICATIONS
35
# Part Number Description Qty.
79 100010113
Sealing Ring,
Ø5.2 × 1.9
1
80 100007975 Governor Shaft 1
81 100011223-0001 Flange Bolt M6 × 32 2
82 100010547 Dowel Pin Ø8 × 8 2
83 100096311 Motor 1
84 100005138 Clamp Ø9.5 × 8 1
85 100017831
Fuel Pipe,
Ø4 × Ø10 × 126
1
86 100010272
Drain Bolt,
M10 × 1.25 × 15
2
87 100010459
Washer
Ø10 × 1.5 × Ø16
2
88 100017644
Oil Seal Ø25 × Ø41.25
× 6, Spiral Grain
1
89 100009272 Ignition Module 1
90 100011268-0003 Flange Bolt M6 × 25 2
91 100007060 Lower Guard 1
92 100004217 Bushing Ø8 × Ø12 × 8 1
93 100009400 Charge Coil 1
94 100011269-0003 Bolt M6 × 28 2
95 100009535 Flywheel 1
96 100007028 Cooling Fan 1
97 100007550 Pulley, Starter 1
98 100011459-0003 Flange Nut M14 × 1.5 1
99 100095986-0001
Recoil Starter
Assembly
1
100 100051113-0011 Fan Cover, Yellow 1
101 100099122-0001 Recoil Starter, Black 1
102 100010894-0001 Washer Ø6 3
103 100011528-0004 Flange Bolt M6 × 10 3
104 100052808 Clamp 1
105 100120416 Start Relay 1
106 100127017
Cylinder Head
Assembly
1
107 100082397 Fuel Bowl O-Ring 1
108
100123334 Main Jet Standard 1
100082378
Main Jet Altitude
1000-2000m
/
100123767
Main Jet Altitude
2000-3000m
/
109 100006039
Fuel Bowl Mounting
Bolt Gasket
1
110 100005725
Fuel Bowl Mounting
Bolt
1
