Champion 100892 - Page 33

100892 - 4500W OPEN FRAME INVERTER
SPECIFICATIONS
33
# Part Number Description Qty.
78 100055591-0007
Flange Bolt M6 x 12,
GB16674
2
79 100146622 Trigger 1
80 100017644 Oil Seal Ø25 x Ø41.25 x 6 1
81 100130948 Lower Guard 1
82 100153854
Stator Assembly, Cu,
Ø156 x 54 mm
1
83 100011540-0007 Flange Bolt M6 x 50 3
84 100126953
Rotor Assembly,
Permanent Magneto,
Ø180 x 64 mm
1
85 100087582 Cooling Fan 1
86 100087581 Pulley, Starter 1
87 100011459-0003 Flange Nut M14 x 1.5 1
88 100153289-0003 Recoil Starter Assembly 1
89 100128650-0001 Fan Cover, Black 1
90 100156547-0001 Recoil Starter, Black 1
91 100010894-0002 Washer Ø6 3
92 100011565-0002
Flange Bolt M6 x 10,
GB16674.1
3
93 100011284-0003 Flange Bolt M6 x 100 3
94 100005152 Clamp Ø11.5 1
