100892 - 4500W OPEN FRAME INVERTER
SPECIFICATIONS
32
# Part Number Description Qty.
1 100011264-0003
Flange Bolt M6 x 16,
GB5789
7
2 100002335 Cylinder Head Cover(Cpe) 1
3 100075045 Breather Tube 1
4 100066138
Gasket,
Cylinder Head Cover
1
5 100002464-0001 Flange Bolt M8 x 60 4
6 100159588 Cylinder Head Assembly 1
7 100149239 Rocker Arm Assembly 2
8 100050881 Guide Plate, Push Rod 1
9 100050896 Valve Collet 4
10 100073758 Valve Spring Seat 2
11 100713979 Spring Valve 2
12 100004599 Oil Seal, Valve 1
13 100010387 Stud Bolt M8 x 34 2
14 100713981 Exhaust Valve 1
15 100009378 Spark Plug F6RTC 1
16 100713980 Intake Valve 1
17 100079792 Cylinder Head 1
18 100061091 Stud Bolt M6 x 98 2
19 100078607 Gasket, Insulator 1
20 100122101 Insulator, Carburetor 1
21 100078606 Gasket, Carburetor 1
22 100153290 Carburetor 1
23 100005717 Fuel Bowl O-Ring 1
24
100005750 Main Jet Standard 1
100005757
Main Jet Altitude
1000-2000m
/
100005766
Main Jet Altitude
2000-3000m
/
25 100006037
Fuel Bowl Mounting Bolt
Gasket
1
26 100005725 Fuel Bowl Mounting Bolt 1
27 100005138 Clamp 1
28 100017831 Fuel Pipe, Ø4 x Ø10 x 126 1
29 100050035 Protection Cover 1
30 100051029-0004 Screw M4 x 6 4
31 100093486 Stepping Motor 1
32 100010947-0001 Screw M4 x 12 2
33 100158241 Stepping Motor Seat 1
34 100033258
Clamp,
Stepping Motor Guide
1
35 100052405 Spring 1
36 100713488 Gasket, Air Filter Base 2
# Part Number Description Qty.
37 100142011 Choke Lever Rack 1
38 100153222 Air Filter Assembly 1
39 100156312 Air Filter Base 1
40 100005078 Air Filter Baffle 1
41 100004771 Air Filter Element 1
42 100087055 Air Filter Cover 1
43 100004949 Air Filter Bolt 1
44 100011463-0002 Flange Nut M6 2
45 100007083 Air Guide, Lower 1
46 100011260-0005 Flange Bolt M6 x 10 9
47 100155656 Gasket, Cylinder Head 1
48 100010558 Dowel Pin Ø10 x 16 2
49 100003243 Piston Ring Set 1
50 100072134 1st Piston Ring 1
51 100072135 2nd Piston Ring 1
52 100072136 Oil Ring 1
53 100149269 Push Rod 2
54 100149234 Lifter, Valve 2
55 100003086 Piston 1
56 100003221 Circlip 2
57 100003123 Wrist Pin 1
58 100003446
Connecting Rod
Assembly
1
59 100010272
Drain Bolt,
M10 x 1.25 x 15
2
60 100010459 Washer Ø10 x 1.5 x Ø16 3
61 100002910-0001 Drain Tube 1
62 100062919 Oil Level Sensor 1
63 100010761 Bearing, TM6205 2
64 100126476 Crankshaft 1
65 100099599 Camshaft 1
66 100010148 Gasket, Crankcase Cover 1
67 100128008 Cover, Crankcase 1
68 100011319-0001 Flange Bolt M8 x 32 6
69 100152738-0001 Oil Dipstick Assembly 1
70 100010550 Dowel Pin Ø8 x 14 2
71 100011215-0001 Flange Bolt M6 x 12 3
72 100122168 Control Assembly 1
73 100011266-0004 Flange Bolt M6 x 20 3
74 100000655 Wire Clip B 3
75 100133378 Ignition Module 1
76 100149610 Crankcase 1
77 100122099 Trigger Support 1
Engine Parts List
